GCP OJT / 3-Tier

UHDC OJT 3-Tier App

External HTTPS Load Balancer, Nginx Web Tier, Internal Load Balancer, GKE App Tier, and Cloud SQL are connected end to end.

DB connected HTTPS domain active Cloud SQL CMEK
Smiling dog on a beach
Sunny service marker
External LB443 HTTPS, Cloud Armor
Web TierNginx reverse proxy
Internal LBPrivate application entry
App TierGKE workload identity
DB TierPrivate Cloud SQL

Runtime Status

Serviceuhdc-ojt-app
App time2026-06-08T19:18:52.269899+00:00
Databaseojt
MySQL userapp_user@10.20.2.21
Database time2026-06-08 19:18:52
Connection statusok
